When managing severe wellhead environments, the physical integrity of your flow control equipment dictates operational safety. Our hydraulic choke valves are forged from 100% virgin tungsten carbide and specialized rugged alloys, presenting a dense, unyielding metallic structure that feels exceptionally heavy and solid to the touch. This dense material composition delivers outstanding resistance against relentless abrasion, aggressive chemical corrosion, and the destructive physical forces of fluid cavitation inherent in high-pressure oil and gas extraction.
To complement this rugged exterior, the internal architecture features advanced sealing technology. We incorporate premium temperature- and pressure-resistant seals, including specialized Teflon and VITON compounds, alongside an optimized stem and seat configuration. When actuated, the internal components engage with a precise, tactile resistance that confirms a flawless barrier against fluid leakage. This meticulous engineering directly supports the demanding performance requirements and extreme working pressures detailed in the technical parameters below, ensuring prolonged operational life even under the most punishing conditions.
Applicable Standards | API Spec 16C, API Spec 6A |
|---|---|
Temperature Ratings | K, L, N, P, S, T, U, V |
Material Class | AA, BB, CC, DD, EE, FF, HH |
Product Specification Level | PSL-1, PSL-2, PSL-3, PSL-3G |
Performance Requirement | PR-1, PR-2 |
Working Pressure | 3000psi, 5000psi, 10,000psi and 15,000psi |
Nominal Diameter | 2-1/16”, 3-1/8”, 3-1/16”, 4-1/16” |
Meeting stringent global petroleum directives requires a manufacturing process rooted in absolute precision. We utilize advanced Hot Isostatic Pressing (HIP) sintering combined with multi-axis CNC machining. Running your hand along the internal bore reveals a flawlessly smooth, mirror-like finish—a direct result of micron-level machining tolerances. This exceptional surface processing minimizes friction and turbulent flow, ensuring the valve components maintain their structural integrity and long-term sealing capabilities under extreme stress.
Every unit undergoes a rigorous inspection and quality control regimen before deployment. Our testing protocols encompass comprehensive raw material metallurgical analysis, exact dimensional verification, hydrostatic pressure testing, and advanced non-destructive testing (NDT). By scrutinizing every microscopic detail and structural weld, we eliminate hidden flaws. This uncompromising approach guarantees that our equipment consistently aligns with the critical safety and environmental mandates specified by API and NACE, providing operators with absolute confidence in their well control systems.
API Spec 16C 3rd edition | Choke and Kill Equipment |
|---|---|
API Spec 6A 21st edition | Specification for Wellhead and Tree Equipment |
API Spec 20E 3rd edition | Alloy and Carbon Steel Bolting for Use in the Petroleum and Natural Gas Industries |
API Standard 53 5th edition | Well Control Equipment Systems for Drilling Wells |
Nace MR0175-2021 | Petroleum and Natural Gas Industries - Material for use in H₂S containing Environments in Oil and Gas |
Operational demands vary wildly across different drilling sites, requiring flexible and responsive flow regulation. To address this, our valves are equipped with versatile drive and control mechanisms. Operators can select from manual overrides, heavy-duty hydraulic actuators, or fully automated centralized control systems. The hydraulic and automated options allow for remote, pinpoint adjustments, emitting a low, steady hum during actuation that signifies immediate and accurate flow modulation, drastically improving site safety and operational efficiency.
Furthermore, we recognize that standard dimensions may not fit every specialized manifold. We offer comprehensive OEM and ODM services to engineer non-standard solutions based on specific client drawings, physical samples, or unique environmental conditions. Whether you require distinct orifice dimensions or specialized manifold configurations, our engineering team adapts the design to fit your exact infrastructure. The configurations listed below represent our core dimensional and pressure capabilities, ready to be tailored to your specific project requirements.
2-9/16" 3,000psi
2-9/16" 5,000psi
2-9/16" 10,000psi
2-9/16" 15,000psi
3-1/8" 3,000psi
3-1/8" 5,000psi
3-1/16" 10,000psi
3-1/16" 15,000psi
4-1/16" 3,000psi
4-1/16" 5,000psi
4-1/16" 10,000psi
4-1/16" 15,000psi
The true measure of industrial equipment lies in its field performance across diverse and unforgiving climates. Our hydraulic choke valves are extensively deployed in critical applications, including wellhead fluid regulation, high-pressure fracturing flowback manifolds, sand-laden oil extraction, and complex coal chemical processing. In these environments, the equipment is constantly subjected to the harsh realities of nature—from the blistering, dust-choked winds of Middle Eastern deserts to the freezing, ice-covered rigs of northern territories.
Despite these extremes, our valves continue to perform with unwavering reliability, preventing costly blowouts and maintaining optimal extraction rates. The visual footprint of our equipment—coated in heavy-duty, weather-resistant industrial paint—can be seen on active rigs worldwide. This widespread adoption is a testament to the meticulous engineering and resilient materials that go into every unit. Below is a representation of the global regions where our flow control technology is actively utilized by major operators to secure their extraction investments.
